Automatic Pile Cage Welding Machine Operation Process
The operation process is designed to be simple, efficient and safe.
Fully leverages the machine’s intelligent PLC control, servo drive and automatic welding systems.
Allows operators to complete high-precision rebar cage production with minimal professional skills.
Ensures stable machine operation and consistent processing quality.
Applicable to all models of our rebar cage rolling welder.
Supports cage diameters ranging from 400mm to 2500mm and three welding combinations.
The operation process of the automatic pile cage welding machine is designed to ensure high efficiency, precision, and consistent quality in rebar cage production. This equipment is widely used in infrastructure projects such as bridges, highways, and high-rise buildings.
Through automated feeding, synchronous rotation, and continuous welding, the machine forms rebar cages quickly while reducing labor costs and human error. Compared with traditional manual production, the automated process significantly improves productivity and ensures uniform spacing and high concentricity of the steel cage.
This standardized workflow is ideal for contractors and rebar processing factories aiming to scale production with stable quality.
Key Features
Fully Automated Welding Process: From feeding to forming, the system ensures continuous production
High Precision Control: Ensures uniform spacing and consistent cage diameter
Labor Saving Design: Reduces manpower from traditional 8–10 workers to fewer operators
Stable Welding Quality: Minimizes welding defects and improves structural strength
Adjustable Parameters: Supports different cage sizes and specifications
High Efficiency Production: One cage can be completed within 20–30 minutes
Technical Specifications
| Parameter | Value |
|---|---|
| Cage Diameter | 500–3000 mm |
| Cage Length | Up to 12 m (customizable) |
| Main Bar Diameter | Φ16–50 mm |
| Spiral Bar Diameter | Φ5–16 mm |
| Control System | PLC / CNC |
| Welding Method | CO₂ Shielded Welding |
| Production Efficiency | 20–30 min per cage |
Applications
Bridge and Highway Foundation Construction
High-Rise Building Pile Foundations
Railway and Metro Projects
Water Conservancy and Energy Projects
Rebar Processing Plants
Why Choose Our Machine
Mature and Stable Technology with Proven Field Performance
High Automation Reduces Labor and Increases Output
Customizable Solutions for Different Project Requirements
Strong Machine Structure for Heavy-Duty Operation
Global Export Experience with Reliable After-Sales Support
Application Case
A highway construction project in Southeast Asia adopted our pile cage welding machine to produce foundation cages.
By switching from manual fabrication to automated welding, the client increased production efficiency by over 40% and reduced labor costs significantly. The machine delivered stable performance, uniform cage quality, and improved project timelines.
FAQ
Q1: What is the operation process of a pile cage welding machine?
A: It includes main bar feeding, spiral bar feeding, positioning, welding, forming, and unloading.
Q2: Is the process fully automatic?
A: Yes, most steps are automated, with minimal manual intervention required.
Q3: How long does it take to produce one cage?
A: Typically 20–30 minutes depending on cage size.
Q4: What welding method is used?
A: CO₂ gas shielded welding for high-quality joints.
Q5: What industries use this machine?
A: Construction, infrastructure, railway, and energy projects.
